• 8 channels of digital audio input via CobraNet
• 24-bit D/A converters with 48kHz sample rate
• 8 line level analog outputs on plug-in barrier strips
• Front panel adjustable analog output level controls.

• included as block in Audia system design software
• may be used with any CobraNet compliant system
• RoHS compliance and AES grounding practices
• CE marked and UL listed power source
• covered by Biamp Systems’ five-year warranty

ARCHITECTS & ENGINEERS SPECIFICATION

The Output Expander shall provide eight channels of digital audio input via CobraNet,® on two rear panel RJ45 connectors. Internal digital-to-analog signal conversion shall be 24-bit, with a sample rate of 48kHz. Eight linelevel analog audio outputs shall be provided on rear panel plug-in barrier strip connectors. Front panel level controls shall be provided for adjustment of the analog audio output signals. A rotary encoder and LCD screen shall be provided on the front panel for programming and setup. Logic Inputs shall be provided for remote control of CobraNet routing assignments. The Output Expander shall be represented as a functional block within Audia® software, for easy inclusion into system designs. The Output Expander shall also be capable of providing additional analog audio outputs from other CobraNet compliant systems or devices. The Output Expander shall be CE marked with a UL/C-UL listed power source, and shall incorporate AES48-2005 Grounding & EMC practices. The Output Expander shall be compliant with EU Directive 2002 /95/EC, the RoHS directive. arranty shall be 5 years. The Output Expander shall be AudiaEXPO.
