Bogen V100 Modular Amplifiers

The Bogen V100 Power Vector Amplifier 100W with 8 module bays for a wide array of inputs and outputs. Modules are available for signal processing and inputs such as: balanced and unbalanced inputs; stereo or mono; telephone systems/PBXs; transformer-isolated; microphones; tone generator; and bridging. The Power Vector automatically senses each module and inserts it into the signal path. A 5-position barrier strip allows for 4/8ohm or 25/70V output loads. When you need an amplifier with flexibility and reliability, the Power Vector V100 is the obvious choice.

Bogen’s Power Vector modular amplifiers offer a wide range of power levels from which to choose, with five
models from 35W to 250W. The amplifiers are designed to work with both high- (70/25V) and low- (4/8-ohm)
impedance speaker systems.
Each model includes eight module bays for plug-in input modules and allows up to four levels of priority
between modules. Two module bays are capable of accepting plug-in signal-processing output modules.
Each module is controlled by an independent volume control with an associated signal/clip LED for signal
status. An 11-segment LED output meter monitors output signal level.
Each model includes a motorized master volume control that can be controlled using a remote volume
control panel (RVCP, sold separately).

8 module bays for inputs and outputs
Each input has a independant volume control

4 levels of priority between modules

125Hz Lo-cut filter for module 6

11-segment LED output level meter monitors the output level of the power amplifier with peak and average meter switch
