Bose ControlSpace EX-12AEC

PROCESADOR PARA CONFERENCIAS 16X16, DANTE

PRESENTACIÓN: PIEZA

Categoría: Etiqueta:


Descripción

Bose ControlSpace EX-12AEC

Bose ControlSpace EX-12AEC Conferencing Signal Processor (Product Code 834316-1110)

Bose ControlSpace EX-12AEC, with an open-architecture design, twelve acoustic echo cancellers (AEC), and 16 x 16 Dante® connectivity, the ControlSpace EX-12AEC conferencing processor provides cost-effective, robust AEC for conference rooms using ControlSpace EX conferencing processors.

Channel AEC expansion
with multiple references to complement ControlSpace EX-1280C processors in larger systems

Adaptable noise cancellation
with non-linear processing and comfort noise on each AEC channel enhances clarity

Dante audio networking
supports 16 x 16 audio channels for connection to an EX-1280C processor and native Dante-integrated microphones

Front-panel interface
features a large OLED display and rotary encoder for setting network parameters and monitoring channel activity

Technical Summary

Signal Processor
32-bit fixed/floating-point DSP 456 MHz/ARM Cortex-A8 600 MHz

Acoustic Echo Canceling Channels
12

PC Configuration Software
ControlSpace Designer software version 5.5 or later

Maximum Calculation
3.6 GIPS / 2.7 GFLOPS

Audio Over IP
Dante, 16 x 16, primary/secondary, rotatable to AEC
