JBL 305P MkII

Name: JBL 305P MkII
SKU: 49404
Availability: BackOrder

JBL 305P MkII Powered 5″ Two-Way Studio Control

The next-generation JBL 305P MkII compact powered studio monitor makes legendary JBL performance available to every studio. With the revolutionary JBL Image Control Waveguide and refined transducers, JBL 305P MkII offers stunning detail, precise imaging, a wide sweet spot and impressive dynamic range that enhances the critical listening capabilities of any modern workspace. Featuring patented technologies derived from the JBL 7 Series and M2 Master Reference Monitors, and sporting a sleek, modern design, JBL 305P MkII delivers outstanding performance and an enjoyable mix experience at an accessible price.

Specifications

LF Driver 126mm (5″)

HF DRIVER SIZE 25mm (1″)

HF DRIVER TYPE Soft dome

Crossover 1725Hz 4th order acoustic Linkwitz-Riley

OK FOR USE NEAR MAGNETICALLY SENSITIVE EQUIPMENT Yes

INPUT SENSITIVITY (-10dBV INPUT) 92dB / 1m

Power Configuration Bi-amplified

HF DRIVER POWER AMP 41W, Class-D

LF Driver Power Handling 41W, Class-D

Frequency Response (±3 dB) 49Hz – 20kHz

Frequency Range (-10dB) 43Hz – 24kHz

LOW FREQUENCY EXTENSION (-10dB) 43Hz

Maximum Continuous SPL 94dB

Maximum Peak SPL 108dB

MAXIMUM PEAK INPUT LEVEL(-10dBV / +4dBu) +6dBV / +20.3dBu

SYSTEM DISTORTION CRITERIA <10% THD at maximum output with full compressor / limiter engagement

ELECTRICAL DISTORTION CRITERIA 0.2% THD @ 1kHz / 2.83VRMS output; <1% THD @ 1kHz, full rated output

Signal to Noise Ratio 75dBA (A-Weighted), 70dBr (unweighted), relative to 2.83VRMS output

Coverage Angle 120° x 90°

Input Connectors 1 x XLR female, 1 x TRS female, balanced

HF TRIM CONTROL -2dB, 0dB, +2dB

BOUNDARY EQ LF Shelf @ 50Hz: -3dB, -1.5dB, 0dB

AC INPUT VOLTAGE 100 – 240VAC (±10%), 50 / 60Hz

ENCLOSURE TYPE Ported

Enclosure 15mm MDF

ENCLOSURE FINISH Matte black PVC

BAFFLE CONSTRUCTION Injection-molded structural ABS

CABINET DIMENSIONS (H x W x D) 298 x 185 x 231 mm (11.75″ x 7.3″ x 9.9″)

DISPLAY CARTON (H x W x D) 354 x 244 x 299mm (13.9″ x 9.6″ x 11.8″)

SHIPPING CARTON (H x W x D) 373 x 260 x 315mm (14.7″ x 10.2″ x 12.4″)

Net Weight (each) 4.73 kg (10.43 lbs)

SHIPPING GROSS WEIGHT 5.72 kg (12.61 lbs)

The next generation of JBL 305P MkII powered studio controls brings legendary JBL performance to any studio. Featuring the revolutionary JBL Image Control Waveguide and enhanced transducers, the JBL 305P MkII delivers incredible detail, precise imaging, a wide sweet spot, and impressive dynamic range that enhances the most critical listening conditions in any modern workspace. With patented technology derived from the JBL 7 Series and M2 Master Reference Monitors, in addition to its sleek, modern design, the JBL 305P MkII offers exceptional performance and an unbeatable experience at a very affordable price.

Patented Image Control Waveguide for detailed imaging and a broad, room-friendly sweet spot
Next-generation JBL transducers for optimized transient response and improved linearity
Patented Slip Stream™ low-frequency port for superior bass performance at all playback levels
Dual integrated, custom Class-D amplifiers provide 82 watts of power for high output and dynamic range
New Boundary EQ settings compensate for low frequency variants introduced by the environment
HF Trim switch adjusts high-frequency output to room acoustics or personal preferences
Flexible connectivity with balanced XLR and 1/4″ TRS inputs, +4dBu / -10dBV input-sensitivity switch and adjustable volume control
Engineered to JBL Linear Spatial Reference design criteria for outstanding accuracy in any working space
Strenuous JBL 100-hour full-power test ensures years of reliability
Sleek, modern design provides a visual upgrade to any studio
