JBL AC25
JBL AC25 Ultra Compact 2-way Loudspeaker with 2 x 5.25” LF
High output, 2-way loudspeaker systems combining flexibility with high fidelity,
The JBL Professional AC25 is an ultra-compact full-range loudspeaker system designed to provide maximum bandwidth and SPL in a single system package and yet be visually unobtrusive. The enclosure design allows for installation very close to walls and ceilings making it an ideal choice for under balcony, column, or wall mounting. The high frequency device is a 1” dome tweeter integrated into a newly designed 90° x 90° waveguide providing even coverage throughout the intended usage area. The combination exhibits smooth power response resulting in extremely natural voicing.
FEATURES
- 90° x 90° waveguide with 25 mm (1 in) dome tweeter
- 135 mm (5.25 in) LF transducer
- Ultra Compact 2-way Loudspeaker with 2 x 5.25” LF
- 450W Program
- Dual Neutrik NL4 connectors plus screw terminal
- Attachment points for optional U-bracket
- 90° x 90° waveguide with 25 mm (1 in) dome tweeter
- 135 mm (5.25 in) LF transducer
- Ultra Compact 2-way Loudspeaker with 2 x 5.25” LF
- 450W Program
- Dual Neutrik NL4 connectors plus screw terminal
- Attachment points for optional U-bracket
SPECIFICATIONS
Frequency Range 80 Hz -20 kHz (-10 dB)
Frequency Response 90 Hz -18 kHz (±3 dB)
Power Rating 225W Cont. Pink Noise
450W Program
900W Peak
450W Program
900W Peak
Impedance 16 ohms
Coverage Pattern 90° x 90°
Dimensions
(H X W X D) 377.8 x 150.3 x 177.8mm
(14.9 x 5.9 x 7.0in)
(H X W X D) 377.8 x 150.3 x 177.8mm
(14.9 x 5.9 x 7.0in)
Weight 7.5 kg (16.5 lb)
