LEA Connect 702

LEA Connect 702 SMART AMP | 2 CHANNELS | 700 WATTS PER CHANNEL

The CONNECTSERIES 702 is a 2-channel amplifier with 700 watts per channel. As part of the Network CONNECTSERIES, the world’s first Internet of Things- (IoT) enabled professional-grade amplifiers, it is perfectly suited for small to medium-scale installations. The 702 features direct HiZ (70V or 100V) or LoZ selectable by channel. With three ways to connect, you can engage the built-in Wi-Fi access point, connect to the venue’s Wi-Fi, or use the FAST Ethernet to connect to any local area network via Cat5 or Cat6 cable.

Then there’s the Cloud…Network CONNECTSERIES is the first professional amplifier family to feature Cloud connectivity. Harness the power of the Cloud for remote control, monitoring, notifications, and more from any of your personal devices. Just connect your amp to a network and start commanding your systems.  Register for your free LEA Cloud account at leaprofessional.cloud

The Network CONNECTSERIES also features analog inputs and external I/O control for remote on/off and fault monitoring.

3 WAYS TO CONNECT

1. Built-in Wi-Fi Access Point
2. Existing Wi-Fi Network
3. Local Area Network

WEB BROWSER-BASED UI

Works on any web browser on any device with no software downloads

CLOUD CONTROL

Remote control and monitoring from anywhere in the world — no VPN needed.

DIRECT LOW-Z & HI-Z

70V or 100V selectable per channel

SMART POWER BRIDGE

Double the power any any single channel without sacrificing other amp channels

UNIVERSAL SWITCH-MODE POWER SUPPLY

Operation from 100VAC – 240VAC +/-15%

ANALOG BALANCED OR UNBALANCED INPUTS

Fully routable balanced or unbalanced RCA analog inputs via input matrix and input mixer in Web UI, SharkWare, or Cloud platform

96KHZ ANALOG DEVICES DSP

Input Routing
48dB/Oct crossover filters
8 Parametric EQ filters
User-adjustable speaker limiters
Real-time load monitoring

EXTERNAL I/O PORT

For Remote ON/OFF and Fault Monitoring, and 4 General Purpose I/O ports coming son

HIGHLY EFFICIENT CLASS-D OUTPUT STAGE

For low AC Current Draw
