Nexo DPU

Nexo DPU Digital Patching Unit

The DPU is an unique tool that will perfectly fit your NXAMPs when used on the road. It offers all the necessary tools to ensure easy patching of the NXAMP power outputs.

World first intelligent output patch

Forget about the classical static output patch panel full of sticky tape and unreadable inscriptions. The DPU communicates directly with the NXAMP and knows which loudspeaker setup is currently running.

It can then automatically route the amplifier’s power outputs to the correct output speakon on its front panel, whatever Nexo’s speaker is connected, in bridge mode or not.

Ultimately, it offers the possibility to link two NXAMP together on the same output, for systems where more than one amplifier is needed.

Fully redundant design

The DPU is powered through a dual fully certified medical grade power supply system. Any of the two lockable power cords can be unplugged anytime without any drop on the audio signal.

The heavy duty ultra low impedance switching matrix used for audio routing is also implemented using a redundant design, ensuring maximum security. Zero configuration Using the DPU is extremely easy ; not only there is nothing to set up, as all routing parameters are automatically configured, but it tests also that all connections to NXAMP are correct.

Usefull display

The DPU provides also crutial information when connecting your Nexo speakers to the NXAMP.

When the NXAMP is muted, the four individual LCD display for each output the name of the speaker, its pin-out and the NXAMP inputs in use. When unmuted, the LCD turns into four easy readeable output meters.

Part of the NXAMP Universal Rack

Together with the DMU (Digital Meters Unit) and the NXAMP4x4, the DPU is part of the NXAMP Universal Rack, the interchangeable standard of power amplifiers for Nexo systems.
