SPECIFICATIONS

AD-C6T

Effective frequency range¹

65 Hz – 20 kHz

Rated noise power / voltage²

60 watts / 31 volts (rms)

Sensitivity [dB]³

Sensitivity at 4m, 100V maximum tap

88

TBD

Rated coverage (-6 dB)⁴

135° conical DMT™

Directivity factor (Q)

6.5

Directivity index (DI) [dB]

8

Maximum continuous SPL [dB]⁵

106

Maximum peak SPL [dB]⁵

112

Nominal impedance [ohms]

16

Recommended amplifier

120 watts

Transformer taps / impedance

16Ω (in bypass setting)
7.5W (70V); 15W (100V) Tap: 667Ω
15W (70V); 30W (100V) Tap: 333Ω
30W (70V); 60W (100V) Tap: 167Ω
60W (70V); N/A (100V) Tap: 83Ω

LF transducer

165 mm [6.5-inch] weather resistant paper cone woofer

HF transducer

19 mm [0.75-inch] aluminum dome tweeter

Input connector type

Euroblock connector with parallel output

Enclosure material

ABS baffle on powder coated steel back can

Grille material

Powder coated steel

Ingress protection

IP-34

Operating environment

Designed for indoor use

Operating temperature range

-20 to 50° C [-4 to 122° F]

Cutout dimension

Ø 245 mm [Ø 9.65-inch]

Net weight

4.3 kg [9.5 lb]

Product dimensions (Diameter x Height)

Ø 280 x 237 mm [Ø 11.02 x 9.32-inch]

Shipping weight

12.6 kg [27.8 lb] (pair packed)

Shipping dimensions (H x W x D)

330 x 737 x 381 mm [13 x 29 x 15-inch] (pair packed)

Included accessories

C-ring and tile rails, rail screws, euroblock connector, cut-out template, tether grille

Optional accessories

AD-MR6 (pre-install mud ring)

Safety Agency

UL1480, UL2043, NFPA90, NFPA70 suitable for use in air handling spaces. Transformer UL registered per UL1876, ROHS, C-Tick X000, CE compliant. Baffle meets UL94-V0 and UL94-5VB flammability rating; in accordance with IEC60849 / EN60849 systems.
