QSC AD-S112-SW
SUBWOOFER DE MONTAJE EN SUPERFICIE 12 »
PRESENTACIÓN: PIEZA
QSC AD-S112-SW
QSC AD-S112-SW 12-inch Subwoofer
12” weather treated woofer
TFR™ (Turbulent Flow Reduction) port provides optimal resonant tuning and high velocity air flow
Maximum peak SPL 121 dB
Suggested filter points: 32 Hz high-pass, 24 dB/octave Butterworth; 100 Hz low-pass, 24 dB/octave Butterworth
Included YMS12 yoke mount maximizes boundary plane coupling while reducing vibration transmission
Optional M10 Kit-C for additional installation versatility
Lightweight ABS enclosures offer long-term durability and lasting good looks
Sealed input panel cover and powder coated aluminum grilles for added weather resistance
Meets IEC60529 IP-54 for dust and splash resistance
Available in black (RAL 9011)
Complete EASE, CF2, CAD, and BIM information available online.
| System Details | AD-S112sw |
| Effective frequency range1 | 30 – 135 Hz |
| Rated noise power / voltage2 | 300 watts / 50 volts (rms) |
| Broadband Sensitivity3 | 90 dB SPL |
| Maximum continuous SPL4 | 115 dB |
| Maximum peak SPL4 | 121 dB |
| Rated impedance | 8 ohms |
| Recommended amplifier power (loudspeaker «program» power) | 600 watts |
| Transformer taps | n/a |
| HF transducer | – |
| LF transducer | 12-inch weather resistant paper cone woofer, 2.5-inch / 64mm voice coil |
| Input connector type | Euroblock connector with parallel output terminals |
| Enclosure material | Painted ABS polymer |
| Grille material | Powder coated aluminum |
| Yoke material | Powder coated galvanized steel (included) |
| Enclosure Details | |
| Ingress protection | IP-54 |
| Operating environment | Designed for indoor and outdoor use |
| Testing | The AD Series loudspeakers qualified for outdoor use using the following tests:
|
| Product Dimensions (HWD) inches | 23.4 x 13.9 x 12.7 |
| Product Dimensions (HWD) mm | 594 x 354 x 323 |
| Net weight | 29 lb / 13.2 kg |
| Shipping weight | 43.1 lb / 19.6 kg |
| Shipping dimensions | 27.5-inch x 21.75-inch x 18.5-inch (698 x 552 x 470 mm) |
| Included accessories | YMS12 yoke mounting system, Euroblock connector, input panel cover |
1 Free-field, -10 dB from on-axis sensitivity | |
Más productos QSC
| Color | Black, White |
|---|
