The VPSI-1 device is designed to allow third party microphones and LED indicators to interface as slave devices to the Vocia standard and emergency Wall Station and standard Desk Station (WS-4/10, EWS-4/10 and DS-4/10) series microphones and to the Vocia Input 6 (VI-6) device for paging via the Paging Ports. Up to four VPSI-1 interfaces can be connected per VI-6 when configured for Vocia Auxiliary Microphone mode. The VPSI-1 can also facilitate third party microphones and control system interfacing with Vocia Wall and Desk Stations (WS-4/10 and DS-4/10). The host Paging Station must be configured for ‘Remote control’ mode within the software.
- Depth: 1.20 in
- Width: 3.20 in
- Height: 6.10 in
- INPUT:
Frequency Response (20Hz to 10kHz): +0, -1dB
Nominal Level (Hardware Configurable): 0dBu, -10dBu, -40dBu and -50dBu
THD + N (20Hz to 10kHz): <0.08%
Effective Input Headroom: 25dB
- Slave interface to Vocia Paging Stations and VI-6 device
- Visual feedback of Paging and Zone status
- Suitable for surface mounting
- Audio, Power and Control over a single Ethernet cable
ARCHITECTS & ENGINEERS SPECIFICATION
The paging station interface shall be designed exclusively for use with Biamp Vocia systems. It shall provide a direct physical connection to Vocia DS-4/10, WS-4/10, EWS-4/10 or VI-6 paging stations and analog audio input devices. It shall be powered from compatible Vocia host devices over standard CAT5e/6 cable. The paging station interface device shall provide breakout connections for balanced audio, RS-232 control, push-to-talk (PTT) and visual feedback LED driver power. It shall support user selectable audio sensitivity. The paging station interface device shall be CE marked and shall be compliant with the RoHS directive. Warranty shall be five years. The paging station interface device shall be a Vocia VPSI-1
