JBL AC299

Name: JBL AC299
SKU: 48889
Availability: BackOrder

JBL AC299 Two-Way Full-Range Loudspeaker with 1 x 12″ LF

AC299 is a compact 2-way full-range loudspeaker system comprised of one 310 mm (12 in) low frequency driver and one 25 mm (1 in) exit/35 mm (1.5 in) voice-coil compression driver. The horn provides 90° by 90° coverage in vertical and horizontal orientation. High-slope passive crossovers minimize band overlap and well-controlled offaxis response. The cabinet is fitted with M10 threaded suspension points. Four threaded inserts located on back of the enclosure allow attachment of an MultiMount® or similar type mounting. AC299 is part of JBL’s AE Application Engineered Series, a versatile family of loudspeakers for a wide variety of fixed installation applications

Specifications

Frequency Range (-10dB) 63 Hz – 20 kHz

Frequency Response (±3 dB) 80 Hz – 18 kHz

System Sensitivity (1w @ 1m) 97 dB

Nominal Impedance 8 ohms

Maximum SPL (1m) 121 dB (127 dB peak)

System Power Rating 350W (1400W peak), 2 hrs (AES rated)
250 W/500 W/1000 W (Continuous/Program/Peak) (IEC rated)

Coverage Pattern 90° x 90° (H x V)

Crossover 1.5 kHz

LF Driver 1 x 12″ woofer (P/N: 5050730), 310 mm (12 in) driver with 66 mm (2.5 in) voice-coil

HF Driver 1 x 2408H-2 driver with 25 mm (1 in) exit/35 mm (1.5 in) voice-coil

Input Connector Dual Neutrik NL4MP connectors plus covered barrier trip terminals

Enclosure 15 mm multi-ply hardwood plywood

Grille Powder coated, 1.5mm perforated steel, with acoustically transparent black foam backing

Finish Textured black paint finish. White (-WH) available upon request. Not available with WRC & WRX finish.

Suspension Attachment 14 x M10 and 4 x M10 for Wall Mount Bracket. Optional U-bracket, L-bracket and wall-mount bracket

Dimensions (H x W x D) 600 mm x 370 mm x 392 mm 23.6 in x 14.5 in x 15.4 in

Net Weight (each) 17.3 kg (38.1lbs)

Crossover Modes Passive

Nominal LF Driver Impedance 8 ohms

Nominal HF Driver Impedance 8 ohms

Robust 15mm enclosure with black textured finish
310 mm (12 in) LF transducer
90° x 90° Waveguide with a 25 mm (1 in) exit 35mm (1.5″) voice-coil compression driver
Dual Neutrik NL4 connectors plus screw terminals
Multiple attachment points for ultimate flexibility

Features

Robust 15mm enclosure with black textured finish
310 mm (12 in) LF transducer
90° x 90° Waveguide with a 25 mm (1 in) exit 35mm (1.5″) voice-coil compression driver
Dual Neutrik NL4 connectors plus screw terminals
Multiple attachment points for ultimate flexibility
