Muxlab MUX-500777-RX-WH
HDMI-USB Over IP PoE WP Receiver, White – UHD-4K The Muxlab 500777-RX-WH HDMI/USB over IP PoE Wall Plate Receiver, UHD4K installs in a double-gang wall box to provide a convenient interface for HDMI display equipment and USB connectivity to manage Smart White Boards and other USB based devices. The unit has one ( 1) HDMIOut, one ( 1) Audio-Out, two ( 2) USB 2.0 Type-A ports, two ( 2) USB 1.1 type-A ports, and one Ethernet Port. It supports video up to 4K 30Hz ( 4:4:4) and 4K 60Hz ( 4:2:0). The HDMI/USB over IP PoE Wall Plate Receiver, UHD-4K allows HDMI and USB equipment to be extended up to 330ft ( 100m). The unit supports an RS232 port plus a Directional IR port to manage remote devices. The device may be powered via a PoE enabled 1Gig Ethernet Switch. Applications: Commercial and residential AV systems K-6 and K-12 classroom AV systems Digital signage Boardroom systems Collaborative PC systems Medical information systemsFeatures: HDMI 2.0b up to 4K 30Hz ( 4:4:4) and 4K 60Hz ( 4:2:0) Audio-Out capability Supports two ( 2) USB 2.0 and two ( 2) USB 1.1 Type-A ports Extend HDMI, 2CH Audio, and USB up to 330ft ( 100m) over Cat5e/6 cable HDCP 2.2 compliant Compatible with 500777-TX, 500759-TX, 500770-TX and 500771-TX over IP Transmitters RS232 and Directional IR for remote control of end-devices PoE powered Managed via Pro Digital Network Controller ( 500811), MuxControl App and 3rd Party Control Apps Specifications: Environment: HDMI and USB connectivity. Devices: Blu-Ray, projectors, monitors, TV, PC, laptops, servers, and Smart White Boards. Bandwidth: 300MHz Signals: HDMI 2.0b ( 4K/30 4:4:4 and 4K/60 4:2:0), USB 2.0, CEC and HDCP 2.2. Connectors: One ( 1) HDMI receptacle Two ( 2) USB 2.0 Type A connectors Two ( 2) USB 1.1 Type A connectors One ( 1) RJ45S for Ethernet connectivity One ( 1) 3-Pin Phoenix connector for RS232 One ( 1) 3.5mm jack for Directional IR<br< div=»»>
- HDMI-USB Over IP PoE WP Receiver, White – UHD-4K The Muxlab 500777-RX-WH HDMI/USB over IP PoE Wall Plate Receiver, UHD4K installs in a double-gang wall box to provide a convenient interface for HDMI display equipment and USB connectivity to manage Smart
