Bose ControlCenter CC-2
Bose ControlCenter CC-2 (Product Code black 768938-0110, white 768938-0210)
Bose ControlCenter CC-2, zone controllers provide volume and A/B source selection for FreeSpace® and ControlSpace® products. Three models are available in either black or white and fit 1-gang electrical boxes in North America. The zone controllers use Cat 5 wiring and can be daisy-chained using the two RJ-45 connectors for simplified wiring.
- ControlCenter Series – Remote end-user interfaces for use with Bose FreeSpace® amplifiers, PowerShare amplifiers and ControlSpace®, processors. Three control configurations offer volume control (CC-1), volume plus A/B source selection (CC-2) and volume plus A/B/C/D source selection (CC-3).
- Variant Options – Available in white or black and is offered in North American, Japanese, and EU form-factors to adapt to common electrical box sizes.
- Support for Decora®-style wall plates – North American and Japanese models are designed for use with Decora-style wall plate covers (not included). The 86×86 mm European model is supplied as a finished wall plate that supports 60 mm screw spacing.
- Custom Labels – Each zone controller includes a sheet of pre-printed labels, with two blanks for custom labeling.
2 RJ-45 connectors which allow daisy-chaining
Maximum Cable Length
FreeSpace and PowerShare: 2000’ (610 m)
ControlSpace: 500’ (152 m) shielded cable, 100’ (30 m) unshielded cable
