Muxlab MUX-500454-POE

Muxlab MUX-500454-POE

This MuxLab 500454-POE-RX HDMI receiver 4K allows HDMI equipment to be connected up to 131ft (40m) at 4K/30 (4:4:4) or 4K/60 (4:2:0) resolutions, or 230 ft (70 m) at resolutions up to 1080p via one (1) Cat 5e/6 unshielded twisted pair cable in a point-to-point configuration. For ease of cabling the extender kit features PoE (PD), including PoC, on both the transmitter and receiver. The HDMI extender 4K supports RS232 and bidirectional IR for end devices remote control.

Applications
Digital signage
Commercial AV systems
Classroom projector systems
Boardroom systems
Collaborative PC systems
Medical information systems

This MuxLab 500454-POE-RX HDMI receiver 4K allows HDMI equipment to be connected up to 131ft (40m) at 4K/30 (4:4:4) or 4K/60 (4:2:0) resolutions, or 230 ft (70 m) at resolutions up to 1080p via one (1) Cat 5e/6 unshielded twisted pair cable in a point-to-point configuration. For ease of cabling the extender kit features PoE (PD), including PoC, on both the transmitter and receiver. The HDMI extender 4K supports RS232 and bidirectional IR for end devices remote control. ApplicationsDigital signageCommercial AV systemsClassroom projector systemsBoardroom systemsCollaborative PC systemsMedical information systems. FeaturesSupports 1080p deep color and full 3D to distances of up to 230 ft (70m) over single Cat5e/6Supports 4K @ 24/25/30Hz (4:4:4) and 4K/60 (4:2:0) to distances of up to 131 ft (40m) over single Cat5e/6Supports RS232Supports Bi-directional IR pass throughSupports all digital audio modesPoE (PD) & PoC on both the transmitter and receiverIncludes IR emitter and IR sensor (carrier-wave)Compatible with 500454 (non PoE version)One (1) HDMI receptacleOne (1) RJ45S for Cat5e/6 unshielded or shielded twisted pairOne (1) DB9 for RS232Two (2) 35mm sockets for IR Sensor & Emitter (carrier-wave)One (1) 2.1mm locking power connectorSpecificationsEnvironment: HDMI 1.4a (3D)Transmission: Transparent to the userBandwidth: 340MHzSignals: HDMI 1.4a protocolPower Supply: Two (2) 110-240V/5VDC power supplies with interchangeable bladesPower Consumption Transmitter: 1.6 Watt Receiver: 3.2 WattTemperature Operating: 0 to 40 CStorage: -20 to 85 CHumidity: up to 95% non-condensingEnclosure: MetalDimension: 4.40″ x 3.00″ x 1.00″ (11.2 x 7.6 x 2.5 cm)Compliance Regulatory: FCC, CE, RoHS, UL, cUL, TUVWeight: 0.9 lbs
