For applications requiring 600 ohm line-matching. Responds to mute bus activation.
– For Applications Requiring 600 ohm Line Matching.
– Transformer Isolation (600 ohms) minimizes ground loop problems when connecting remote equipment (greater than 15 feet)
– Responds To Mute Bus Activation, via Mute SEND module or switch-closure
– Responds To Both Mute Bus #1 And Mute Bus #2 By Default (cut jumper(s) to disconnect individual mute bus)
– Connector: removable terminal block
- Performance Input: 600 tb
- Input Sensitivity: -16 dBu
- Gain (Adjustable): -1 dB (fixed)
- Maximum Input: +20 dB
- Physical Connector:Removable Terminal Block
